Rix DBH D6 Thermal Riflescope
Core Characteristics of the Rix DBH D6 Thermal Riflescope
- Sensor Resolution: 640×512
- Objective Lens: 60mm
- Optical Zoom: 3
- Display Resolution: 2560 x 2560
- Operating Time: 8h
DBH D6 Thermal Riflescope Specifications
Sensor Specifications
- Type: VOx Uncooled
- Resolution, pixels: 640×512
- Pixel pitch, μm: 12
- NETD, mK: <20
- Frame Rate, Hz: 60
Optical Specifications
- Objective Lens, mm: 60 F1.0
- Optic Zoom, x: 3
- Field of View, degrees / yd @ 100 yd: 7.3° × 5.8°
- Digital Zoom, x: 1 to 6
- Eye Relief, mm: 60
- Diopter Adjustment, D: -5 to +2
- Detection Range, m/yd: 3280
Display Specifications
- Type: OLED
- Frequency, GHz: 2.4GHz
Video Recorder
- Video / Photo Resolution, pixels: 1280×1280
- Video / Photo Format: .mp4 / .jpg
- Built-in Memory, GB: 64
Physical Specifications
- Degree of Protection, IP code: IP67
- Operating Temperature Range, °F: -13 to +122
- Weight, lb: 2.9
- Dimensions, inch: 10.3 × 3.3 × 3.8
Connections and Compatibilities
- Battery Type: 18650
- Capacity, mAh: 3200
- Operating Time on Battery Pack (at t=72°F), h: 8
- External Power Supply, V: 5V (Type C USB)
- Max Recoil Power on Rifled Weapon (Eo), g/Joules: 1000g / 6000Joules
- Ballistic Calculation: Yes
