Rix Storm S3 Thermal Riflescope

Rix Storm S3 Thermal Riflescope

Rix Storm S3 Features

• 12µm sensor boasting, NETD<25mK, and a 50Hz refresh rate
• Resolution Enhanced Technology (RET) doubles the number of pixels and employ advanced Al algorithms to optimize the content displayed by these additional pixels.
• 1024×768 Full Color OLED
• Replaceable 18650 battery that enables the continuous operation for up to 6 hours
• 90-degree, quick-detach battery cap design facilitates effortless battery swapping
• Intuitive operating system
• Return to Center function after zeroing will automatically reposition the reticle closer to the center of the x-axis and y-axis.
• Adjustable Picture-in-Picture (PIP) image
• Aluminum alloy construction
• Powerful Base Magnification of 3.5x
• 1000g Impact Resistance
• IP67 Waterproof
• Wi-Fi integration with RIX+ APP
• Photo, Video Recording and Built-in MIC
• Recoil Activated Video feature

Storm S3 Thermal Riflescope Core Characteristics

• Sensor Resolution: 384×288
• Objective Lens: 35mm
• Optical Zoom: 3.5
• Display Resolution: 1024×768
• Operating Time: 6h

Rix Storm S3 Specifications

Sensor Specifications

• Type: VOx Uncooled
• Resolution, pixels: 384×288
• Pixel Pitch, µm: 12
• NETD, mK: <25
• Frame Rate, Hz: 50

Optical Specifications

• Objective Lens, mm: 35
• Optical Zoom, x: 3.5
• Field of View, degrees / yd @ 100 yd: 7.5° / 13.2 yd
• Digital Zoom, x: 1 to 4
• Eye Relief, mm: 48
• Diopter Adjustment, D: -5 to +5
• Detection Range, m/yd: 1800 / 1968

Display Specifications

• Type: OLED
• Resolution, pixels: 1024×768

Wi-Fi

• Wireless Protocol: Wi-Fi
• Frequency, GHz: 2.4 GHz

Video Recorder

• Video / Photo Resolution, pixels: 1024×768
• Video / Photo Format: .mp4 / .jpg
• Built-in Memory, GB: 32

Physical Specifications

• Degree of Protection, IP code: IP67
• Operating Temperature Range, °F: -4 to +122
• Weight, lb: 0.97
• Dimensions, inch: 5.3 × 2.5 × 2.2

Connections and Compatibilities

• Battery Type: 18650
• Capacity, mAh: 3200
• Operating Time on Battery Pack (at t=72°F), h: 6
• External Power Supply, V: 5V (Type C USB)
• Max Recoil Power on Rifled Weapon (Eo), g/Joules: 1000g / 6000 Joules
• Compatible Mounts: Picatinny mount
