Pulsar Telos XP50 Thermal Monocular 2.5-10x 640x480 Resolution

✨  Pulsar Telos XP50 Thermal Monocular   ✨

Features:

• Microbolometer resolution: 640x480
• Frame Rate: 50Hz
• Display resolution: 1024x768
• Display type: AMOLED
• Objective lens: F50/1.0
• Magnification: 2.5-10x (x4 digital zoom)
• NETD: <18mK

Adaptable for left- and right-handed use
The vertical symmetrical layout of the controls allows Telos to be used with both hands with the same degree of comfort − the buttons are located in a row on the top panel, and the lens rings are used for focusing and changing magnification.

1800 m detection range
A powerful long-distance F50/1.0 objective lens combined with a 640x480@17µm highly-sensitive thermal imaging sensor provides exceptional detection capabilities.

Fast aperture F50/1.0 germanium lens
Germanium F50/1.0 lens features high infrared transmission in the LWIR range.

Built-in video recorder with 64GB internal memory
The Telos has a built-in video recorder. The increased 64GB internal memory of the Telos can store hours of video and tens of thousands of photos.

Stream Vision 2. Wi-Fi integration with iOS and Android devices
Built-in Wi-Fi connects the Merger LRF to Android and iOS smartphones via the Stream Vision 2 mobile application.

High-contrast AMOLED Display
A high-contrast AMOLED display has an improved colour rendering, power saving and quick-response, providing sharp and smooth images observing even under frosty conditions.

Dual Wi-Fi waveband support 2.4 / 5 GHz
In Merger LRF thermal imagers, the standard smartphone connection frequency range via a 2.4 GHz Wi-Fi channel is complemented with an effective 5 GHz range.

IPX7 submersion waterproof rated
IPX7 waterproof-rated for protection from heavy rainfall, snow or other precipitation. The unit is designed to run flawlessly, even after submersion in up to 1 meter of water for up to 30 minutes.

A selection of 8 color palettes
A choice of 8 color palettes allows the user to optimize the unit for specific tasks as well as react to changing observation conditions. White Hot, Black Hot and Red Hot are optimal for object detection, Rainbow and Ultramarine help increase chances for recognition & identification, while Red Monochrome, Sepia and Violet are most suitable for long observation in the night.

Specifications:

Sensor

• Type: Uncooled

• Resolution: 640×480 pixels

• Pixel Pitch: 17 µm

• NETD: <18 mK

• Frame Rate: 50 Hz

Optics

• Objective Lens: F50 / 1.0

• Magnification: 2.5–10x (4x zoom)

• Field of View (HxV): 12.4° x 9.3° / 21.8m x 16.3m at 100m

• Eye Relief: 14 mm

Display

• Type: AMOLED HD

• Resolution: 1024×768

Range Performance

• Detection Range: 1800 m

Video Recorder

• Resolution: 1024×768 pixels

• Format: .mp4 / .jpg

• Built-in Memory: 64 GB

Wi-Fi

• Wireless Protocol: Wi-Fi

• Wireless Standard: IEEE 802.11 b/g/n/ac (WPA)

• Frequency: 2.4 / 5 GHz

Environmental Characteristics

• Degree of Protection: IPX7 (waterproof)

• Operating Temperature Range: -25°C to +40°C

Connections and Compatibilities

• Mount Type: 1/4"

• Supported Application: Stream Vision 2

Power Supply

• Output Voltage: 3.0–4.2V

• Battery Type: LPS 7i Li-Ion Battery Pack

• Battery Capacity: 6400 mAh

• Operating Time on Battery Pack (at 22°C): 8.5 hours

• External Power Supply: 5V, 9V (USB Type-C Power Delivery)

Weight & Size

• Body Material: Rubber armored reinforced plastic
