InfiRay Outdoor FINDER FH35R V2 Thermal Rangefinder Monocular

✨  InfiRay Outdoor FINDER FH35R V2 Thermal Laser Rangefinding Monocular ✨

The InfiRay Outdoor FINDER V2 combines a powerful thermal viewer with a handheld laser rangefinder. A 640×512 thermal sensor paired with a 3× 35 mm f/0.9 lens provides a crisp image with ample room for digital zoom.

The FINDER V2 pairs 800-yard infrared laser rangefinding capability (continuous or single capture) with a 1,750-yard thermal detection range in a compact unit that fits in the palm of your hand. The FINDER V2 ships with two IBP-2 batteries, each providing 3+ hours of run time. A proximity sensor automatically powers off the display when moved away from the viewer’s eye to reduce power consumption and visible light signature.

Optics

• Objective Focal Length: 35mm
• Focusing Mechanism: Manual Focus
• Objective Lens Material: Germanium
• Detection Range: 1750 Yards
• Digital Magnification: 4X
• Horizontal Angular Field of View: 12.6°
• Optical Magnification: 2X
• Vertical Angular Field of View: 9.4°
• Objective Diameter: 35mm
• Objective F#: 0.9
• Display Type: AMOLED
• Eye Relief: 20mm
• Display Resolution: 1024×768

Features & Performance

• Color Palettes: White Hot, Black Hot, Red Hot, Highlight, Ironbow, Rainbow
• Rangefinder: Integrated 800yd LRF
• Picture-in-Picture: Yes
• Stand-by Mode: Yes
• Image Capture: Yes
• WiFi: Yes
• Mobile App: Yes
• User-Updatable Firmware: Yes
• Onboard Recording: Yes
• Connector Output: Power/Data
• Connector Type: USB-C
• Storage Capacity: 32GB
• Run Time: 3+ Hours
• Power Source: USB-C External, IBP - 2 Li-ion Battery Pack
• Startup Time: <10 Seconds, Instant from Standby
• External Power Source: USB-C
• Country of Manufacture: China

Environmental Specifications

• Operating Temperature Range: -4°F ~ 122°F
• Ingress Protection: IP67

Physical

• Length: 6.30 in
• Width: 3.54 in
• Height: 1.97 in
• Housing Material: Aluminum
• Weight: 14.11 oz

Sensor Specifications

• Sensor Type: InfiRay MICRO II
• Sensor Pixel Size: 12μm
• Thermal Sensitivity: <25mk
• Non-Uniformity Correction (NUC): Manual, Automatic, Semi-Automatic
• Spectral Response: 8-12 Microns
• Sensor Frame Rate: 50hz
• Device Technology: Thermal Imaging
• Sensor Resolution: 640×512

Resources

• Manual
