AGM Global Vision Voyage LRF TB50-640 Thermal & Digital Day / Night Vision Binocular with Rangefinder

✨  AGM Global Vision Voyage LRF TB50-640 Thermal Binocular with Rangefinder  ✨

The AGM Voyage TB50-640 Fusion Thermal & Digital Day/Night Vision binocular features a thermal viewing channel with an incredible 12 micron 640x512 thermal detector. This thermal sensor possesses an industry leading sensitivity rating of sub-20mK (millikelvin), ensuring that not only are human-sized heat signatures detectable at up to 1.6 miles (2600m), but also that foliage and other background imagery will be crisp and detailed in closer distances/ranges.

The Voyage also come outfitted with a digital night vision channel, which is great for aiding in recognition of targets after the thermal channel has detected a potential target. The built-in 1000m Laser Rangefinder simply takes the Voyage to another level.

Features

• Dual-spectrum image fusion and object highlight (detail enhancement and target recognition)
• Selection of thermal view channel, visible light channel, or both them combined
• Thermal resolution: 640×512
• Optical resolution: 2560×1440
• NETD less than 20 mK (25°C, F#=1.0)
• Digital Detail Enhancement (DDE)
• Dynamic Noise Reduction (3D DNR)
• Adaptive Automatic Gain Control (AGC)
• Ultra-low illumination (optical channel), B/W: 0.001 lux @ (F1.0 , AGC On)
• Video recording, replay, picture snapshot and search (capable to review the event on device)
• Wi-Fi hotspot
• Eye-safe laser rangefinder (up to 1,000 m distance detection with measuring accuracy 1 m)
• GPS module
• Digital magnetic compass
• Inclination sensor
• Proximity sensor to save power
• Up to 8 hours continuous operation
• Waterproof, IP67

Includes

• Battery Charger
• Power Cable
• Lens
• Cloth
• Two Wrist Straps
• Neck Strap
• Six 18650 Batteries
• Power Adapter
• User Manual
• Carrying Case

Specifications

• Magnification: 3.5× - 56×

• Interpupillary Distance: 60 mm to 70 mm

• Digital Zoom: 1×, 2×, 4×, 8×, 16×

• Detection Range: 2,600 m/yd (6’ object)*

• Flat Field Correction (FFC): 905 nm (Class 1)

• Palettes: Optical, White Hot Thermal, Black Hot Thermal, Red Hot Thermal, Image Fusion

• Diopter Adjustment: 0.39-inch, OLED, 1024×768

• Battery Type: Three 18650 batteries

• Image Sensor: Vanadium Oxide Uncooled Focal Plane Array

• Resolution: 640 × 512

• Pixel Pitch: 12 μm

• Response Waveband: 8 μm to 14 μm

• NETD: Less than 20 mK (25°C, F#=1.0)

• Field of View: 8.7° × 7.0°

• Aperture: F0.9

• Lens (Focal Length): Less than 20 mK (25°C, F#=1.0)

• Monitor: 0.39-inch, OLED, 1024 × 768

• Storage: Built-in memory module (64 GB)

• Snapshot: JPEG, 1600 × 1200

• Battery Operating Time: Up to 8 hours

• Battery Capacity Display: Yes

• Protection Level: IP67

• Mounting: 1/4”-20 UNC

• Cable Output: USB Type-C port
• Dimension (L × W × H): 217 × 155 × 88 mm (8.5 × 6.1 × 3.5 in)

• Weight: 1.12 kg (2.5 lb)

• Storage Temperature Range: -40°C to 70°C (-40°F to 158°F)

• Picture In Picture Mode (PIP): Yes

• Video Recording: MP4, 1600 × 1200

• Measuring Distance of Laser Rangefinder: Max. 1,000 m

• Laser Wavelength: 905 nm (Class 1)

• Eye Relief: 15 mm

• External Power Supply: DC 5V/2A, Max.10W, Type-C port

Resources

• User Manual
• Data Sheet
