AGM Global Vision Sidewinder TM25-384 Thermal Monocular 2-16x 25mm

✨  AGM Global Vision Sidewinder TM25-384 Thermal Monocular   ✨

The AGM Sidewinder TM25-384 Thermal Monocular boasts a 25mm Germanium lens and a 384x288, 12 micron, sub-20mK thermal detector. The Sidewinder also utilizes a removable, non-proprietary 18650 rechargeable battery which powers the unit by offering up to 7 hours of operating time, built-in to a robust rubber armored housing for added durability and protection.

Features

• 12μm, 384×288 resolution detector
• Highest thermal sensitivity (NETD <20mK)
• Advanced image processing (Digital Detail Enhancement, digital Noise Reduction and NLM algorithm)
• 50 Hz image frame rate
• 1024×768 resolution OLED display
• Built-in memory supports video/audio recording and snapshot capturing
• 64 GB memory module
• Wi-Fi hotspot
• 1×, 2×, 4× and 8× digital zoom
• Replaceable and rechargeable Li-Ion battery
• Up to 7 hours continuous running
• External power supply capability
• Waterproof

Characteristics

• Detector type: Vanadium Oxide Uncooled Focal Plane Array
• Refresh rate: 50 Hz
• Resolution: 384 × 288
• FOV: 10.5° × 7.9°

Includes

• Battery Charger
• USB Cable
• Power Adapter (US and EU plugs included)
• 18650 Rechargeable Battery
• Lens Cloth
• Wrist Strap
• Carrying Case
• User Manual
• Protective Bag

Specifications

• Palettes: Black Hot, White Hot, Red Hot, Fusion
• Dimensions: 188 × 58 × 65 mm (7.4 × 2.3 × 2.6 in)
• Interface: USB Type-C
• Pixel Interval: 12 μm
• Magnification: 2× - 16×
• Detector Type: Vanadium Oxide Uncooled Focal Plane Array
• Response Waveband: 8μm to 14μm
• FFC (Flat Field Correction): Auto, Manual, External Correction
• Highest Temperature Spot Tracking: Yes
• Standby Mode: Yes
• Refresh Rate: 50 Hz
• Aperture: F1.0
• Detection Range (6' object): 1250 m
• NETD: ≤ 20 mk (@25°C), F#=1.0
• Lens (Focal Length): 25 mm
• Power: 5 VDC/2 A, 1.75 W
• Field of View (H × X): 10.5° × 7.9°
• Digital Zoom: 1×, 2×, 4×, 8×
• Diopter Adjustment Range: -5 to +3 dpt
• Monitor: 1024×768, OLED
• Storage: Built-in memory (64 GB)
• Record Video: Yes (on-board)
• Capture Snapshot: Yes
• Battery Type: One 18650 Replaceable Rechargeable Lithium Battery
• Wi-Fi: Yes
• Battery Operating Time: Up to 7 hours
• Weight: 500 g (1.1 lb)
• Working Temperature/Humidity: -30°C to 55°C (-22°F to 131°F)
• Protection Level: IP67

Resources

• User Manual
• Data Sheet

Export Restrictions:
Product shown herein is subject to US export regulations and may require a license prior to export. Any diversion contrary to US Government regulations is prohibited.
